Examples

Live, interactive examples — each with a framework switcher, full source, and reset. Drag nodes, pull connections, edit widgets right in the preview.

Showcases

MCP live (AI builds the graph) Start @xenolithengine/graph-mcp-server locally, click Connect, then ask Claude Desktop / Cursor to build a graph. The AI calls list_node_types → add_node → connect_pins → auto_layout. "I describe it, the editor builds it." React

Visual stepping debugger Run a graph one node at a time. Yellow ring = paused; green = executed; red = breakpoint. The inspector shows live inputs/outputs and per-node timing. Debug your AI workflow on the canvas — like Chrome DevTools, but for nodes. React

Time-travel scrubber Rewind a graph run. Drag the timeline through every step and watch the highlights replay — green = done, yellow = the step under inspection. The inspector shows that step’s inputs and outputs. React

Graph diff (PR review) Two versions of a graph side by side, with structural diff highlights — green = added, red = removed, yellow = modified. Drop-in PR-review for node graphs. React

Per-node cost heatmap A RAG pipeline with per-node latency badges — cool blue → hot red. Press Pulse to see metrics breathe. Drop-in observability overlay; no OSS competitor ships it. React

LLM workflow builder Input → Prompt → Model → Output. Press Run; the chain walks in topological order, the active node glows, the completion streams into the Output. A prettier LangFlow, on Xenolith. React

Audio synth (Web Audio) A real synth built on the graph — Oscillator → Filter → Gain → Output. Knobs are node widgets; Play wires live AudioNodes and lights the active chain. It makes sound. React

Save & restore The whole graph is JSON. Download / upload a .json file, and autosave to localStorage on every edit (driven by useGraphJSON). Reload the page — it comes back. React · Vue · Svelte · Solid · Angular

Image pipeline (WebGL) A real image-filter pipeline — Source → Exposure → Saturation → Hue → Blur → Vignette → Result. Each node is a live GLSL fragment pass. Drag a slider and the result re-renders; drop your own image; download the PNG. React

Diagram edges Edges as a diagramming primitive — text nodes wired with directional arrowhead markers, edge labels (pass / fail / retry), and an animated flowing dash on the main path. Toggle the flow. React

Stress test (1000s of nodes) Generate hundreds → thousands of WebGL nodes wired into a chain. Live FPS + node-count overlay top-right; the panel counter is driven by the reactive `useNodes()` hook. Zoom floor dropped to 5% so 10k+ nodes fit on one screen. React

Nodes

Mount an editor The honest minimum: register a node type, add one, frame it. Xen is the default theme — no setup. React · Vue · Svelte · Solid · Angular

Load a graph Load a real saved xenolith.v1 graph and reframe it. Built-in controls + a reload panel. React

Widgets

Built-in widgets Every built-in widget — slider, number, toggle, combo, color, text — on one node, in WebGL. React

Custom canvas widget The simplest custom widget: a click/drag level bar, drawn in WebGL — no DOM. The value flows back to your app via the standard widget callback. React

Bring your own UI Four widgets that are real framework components (async-select, file drop, CodeMirror, sparkline), themed via --xeno-*. React

Conditional widgets Declarative `displayOptions.show(state)` — n8n-style. One HTTP Request node hides `body` until the method needs one, and `token` until auth is `bearer`. Pure schema: no `setNodeWidgets` plumbing in the host. The node re-layouts and edges stay attached as widgets appear and disappear. JS · React

Per-node canvas drawing Sparkline + ColorPreview nodes — each paints its own body via a CanvasWidgetController (the equivalent of LiteGraph onDrawForeground). The sparkline rolls a live plot of the upstream slider; the swatch fills from `node.state.tint`. Anything you can draw on a `<canvas>` can be a node body. JS · React

Interaction

Events → your state Typed event callbacks wired to app state: a live log, selection inspector, widget values. React · Vue · Svelte · Solid · Angular

Mobile / tablet (touch demo) Touch-first demo for testing pinch, two-finger pan, long-press context menu, and the drawer-mode palette on narrow viewports. Includes a fullscreen toggle. Open this URL on an iOS device or in the iOS Simulator — see docs/TESTING-ON-IOS-SIMULATOR.md. JS

Properties sidebar A "fat" node with 8 widgets opts into the docked properties panel via the per-widget `showInSidebar: true` flag. Edit live — the same widget renders inline AND in the panel; no separate sidebar component to author. Themed via --xeno-*. Open programmatically: `editor.openSidebar(nodeId)`. JS · React · Vue · Svelte · Solid · Angular

Two-way data binding Both binding levels in one: `useSelection()` edits the selected node’s widgets; `useGraphJSON()` binds the whole graph ⇄ JSON. No manual event wiring. React

Type conversions Typed pins of different types refuse to connect — unless you register a conversion. NumberSource (out: number) won’t wire into TextSink (in: text) until `types.registerConversion("number", "text", String)` is called. Toggle the cast live; the existing edge drops when it disappears. JS · React

Subgraph breadcrumb Nested template instances (Pipeline → Stage → primitives). Dive in by double-click OR programmatically; the breadcrumb in the top-left tracks the path (Root › Pipeline › Stage) and pops any segment. Auto-themed via --xeno-*. Opt-out with `editor.setBreadcrumbVisible(false)`. JS · React

Palette sidebar (drag to spawn) 16 schemas across 5 categories (data / math / transform / logic / io) listed in a docked palette on the left. Drag any tile onto the canvas — the editor inserts the node at the drop point via its built-in `node:drop` handler. Configure with `editor.setPaletteSidebar({ side, filter })`. JS · React · Vue · Svelte · Solid · Angular

Connection validation Typed Blueprint pins refuse mismatched wires automatically (a string won’t plug into a number). A custom guard adds cycle prevention on top. Every attempt is logged live. React

Export to image Export the whole graph — not just the viewport — to a Blob at any scale. Download PNG, retina 2×, or JPG straight from a panel. React

Styling

Edge path styles Per-edge `pathStyle`: bezier (default Xen S-curve), smoothstep (rounded orthogonal), step (90° elbows), linear (straight). Set on construction or live via `editor.setEdgeOptions(id, { pathStyle })`. Same wire colour / animated dash / arrowhead contract regardless of shape. JS · React

Theming Theme is a reactive prop — flip Xen ⇄ Liquid Glass at runtime; panels/widgets restyle via --xeno-*. React

Viewport

Viewport & minimap Built-in controls (zoom/fit/reset/undo/redo/save/lock), toggleable minimap, live useNodes/useViewport readout. React

Layout

Nested auto-layout (ELK) Three levels of nested macros — Encoder/Decoder containing Attention/FFN containing leaf ops. ELK respects the hierarchy (children stay inside their parent frame); dagre ignores parent and pancakes everything. Toggle to see the difference. JS · React

Auto-layout (dagre) A messy 14-node DAG snaps into a clean layered layout. Toggle LR/TB; Cmd+Z restores the mess in a single undo step. JS · React
